Do You want cost-effective speed and reliability ?
If so, your future is now with the N.C.S. Computer Group
IP65 Server i7
WELCOME. The new SYSTEM with the i7 CPU. The Server, Mercury i7, is designed to operate in very hostile environments, where an office Server or an assembled PC does not provide a high level of reliability.

Dimensions: W=19" x H= only 1U (44.4mm / 1.75") x D = 250mm (9.84")

FEATURES :
  • Based on SBC Broadwell i7-5650U 3.2 GHz. fanless (9.5W)
  • 2 x SO-DIMM DDR3L 1600 / 1333MHz Dual CH
  • 1 x full size (mSATA),1 x half size Mini PCIe
  • Intel HD Graphics 6000 - 2xHDMI 1.4a Up to 2560x1600@60Hz,
        1 LVDS 24bit Up to 1920 x 1080
  • Dual Gigabit LAN 10/100/1000 Mbps - I211AT + I218LM
  • Realtek ALC662 HD codec
  • 5 x USB 2.0 ports, 4 x USB 3.0 port, 4 COMs, 8 GPIO TTL
  • 1 x SATA ports, TPM chip (option)
  • Operating Temperature - 10C ~ 70C (14F ~ 158F)
  • Operating RH 5%~ 95% (non-condensing)
  • Available with O.S. Linux on the FLASH DISK
  • Power Supply 85-265 Vac / +12 Vdc / + 24 Vdc / - 48 Vdc
  • Fully IP65 aluminium enclosure 19"/1U d=250mm (9.84")
  • Many options are proposed with our systems: several models of     industrial keyboards, TS, IP65 MOUSE, TRACK-BALL, FLASH DISK     TFT monitors from 6.4" up to 23" and HB TFT up to 1600 m
  • N.C.S. is compliant with the European Union Directive "RoHs"
